Schneider Electric SpaceLogic SCD2 Duct CO2 and Temperature Sensor
A SpaceLogic duct sensor combining carbon-dioxide and temperature measurement with analogue outputs and a field-replaceable temperature module for ventilation and plant-room monitoring.
Schneider Electric SCD2XAXCCX is available from EnergyX Egypt for technically reviewed building-management projects and integration support.
SpaceLogic SCD2 Series overview
The SCD2XAXCCX supplies duct CO2 and temperature data to compatible building controls. It supports demand-based airflow strategies while avoiding an unnecessary humidity channel. The replaceable temperature module helps maintain the sensing assembly over its service life.
Key features
CO2 and temperature sensing
Duct-mount design
Analogue integration
Field-replaceable temperature module
Suitable for third-party BMS inputs
Technical specifications
Sensor Type: Duct CO2 and temperature sensor
Measurements: CO2 and temperature
Output: Analogue
Co2Range: Selectable up to 5000 ppm
Temperature Range: -40 to 60 °C
Mounting: Duct
Applications
Air-handling units
Fresh-air control
Plant rooms
Commercial ventilation
Verified compatibility
BMS analogue inputs
EcoStruxure Building Operation through compatible controllers
Review the official Schneider Electric source linked on this page and confirm the final controller, power, network and project requirements before ordering.
